powersoft D-Cell 504 - Disassembly the Power Supply; Disassembly the Amplifier Board

3 Disassembly the power supply
1. Remove the six top cover xing screws
2. Carefully remove the PSU board from the heat
sink
4 Disassembly the amplier board
1. Remove the six top cover xing screws
2. Carefully remove the PSU board from the heat
sink
FIGURE 1: DC Power supply: remove six screws.
FIGURE 2: AC Power supply: remove six screws.
FIGURE 3: D-Cell 504 amplier board: remove six screws.
