Pinouts
Network Connector RJ45 pinout
1 2 3 4 5 6 7 8
Color code (TIA/EIA-568-B) Pin
ORANGE / WHITE 1
ORANGE 2
GREEN / WHITE 3
BLUE 4
BLUE / WHITE 5
GREEN
6
BROWN / WHITE 7
BROWN 8
Ch 4
Ch 3
Ch 4
Ch 3
Ch 4
Ch 3
Outputs (2 Channel Versions)
CH4 - CH3 Balanced Inputs
Outputs (4 Channel Versions)
CH2 - CH1 Balanced Inputs (4 Channel Version)
CH4 - CH3 Line Level Outputs (2 Channel Version) GPI
Ch 1
Ch 1
Ch 3
Ch 2
Ch 2
Ch 4
I4
I2
I3
I1
5V
