powersoft Quattrocanali 1204 User Manual

E
INPUT
OUTPUT (single ended)
F
GPO/ALARM
REMOTE ON | REMOTE OFF
REMOTE LEVEL
Phoenix MC 1,5/12-ST-3,81 1803675 Phoenix PC 5/ 8-STF1-7,62 1777891
INPUT (link channel pairs)*
INPUT (Analog Inputs not in use)
* Quattrocanali 4804 without DSP only
Quattrocanali 2404 without DSP only
Quattrocanali 1204 without DSP only
Phoenix MC 1,5/12-ST-3,81 1803675
Phoenix MC 1,5/12-ST-3,81 1803675
Phoenix MC 1,5/4-ST-3,81 1803594
OUTPUT (bridged)
G
H
I
J
common
common
common
common
6 | Quattrocanali Series
Ch 4
Ch 3
Ch 2
Ch 1
(or Master)
Ch 4
Ch 1
Ch 4
Ch 3
Ch 2
Ch 3
Ch 2
Ch 3
Ch 2
Ch 1
Ch 4
Ch 1
