The trim tab also serves as an anode to
protect the engine from electrochemical
corrosion. Never paint the trim tab as it
will become ineffective as an anode.
1. Trim tab
2. Bolt
Trim rod (tilt pin)
The position of the trim rod determines the
minimum trim angle of the outboard motor
in relation to the transom.
Tilt lock mechanism
The tilt lock mechanism is used to prevent
the outboard motor from lifting out of the
water when in reverse gear.
1. Tilt lock lever
To lock it, set the tilt lock lever in the “ 1”
(lock) position. To release, push the tilt lock
lever in the “1 ” (release) position.
Tilt support lever for power trim and
tilt or hydro tilt model To keep the outboard
motor in the tilted up position, lock the tilt
support lever to the clamp bracket.
