INSTRUCTIONS PL600/PL1000
21
6) Maintenance and Disposal
The maintenance operations must be performed in strict compliance with the safety directions provided in the manual
and according to the applicable legislation and standard.
In order to have good and safety performances, test the gate-automated system weekly and have qualified
installation personnel to check and maintain the system at least every 6-month.
6.1 Maintenance
Some electronic components and the batteries may contain polluting materials; do not pollute the environment. Make
sure the recycling or disposal systems available under the regulations locally in fore.
PL600/PL1000 are consist of different types of materials; some of them can be recycled such as aluminum, plastic,
electric cables while some need to be disposed, such as electronic boards.
6.2 Disposal
7) Additional Information
After you have added or removed any devices, the automation system must be tested again according to the
operation mentioned in paragraph 5 “Testing”.
7.1 Adding or Removing Device
8) Technical Characteristics
8.1 PL600/ PL1000
Motor
Gear type
Peak thrust
Nominal thrust
Power supply
Nominal input power
Maximum operating current
Maximum gate weight
Maximum gate length
Duty cycle
Operating Temperature
Dimension
Weight
Main power supply
Back-up battery
Transformer
Receiver board
24Vdc motor with mechanical release
Worm gear
6500N
6000N
24Vdc
2.5A
5.5A for maximum 10 seconds.
600 kg per leaf
8 meters
20%
-20℃~+50℃
333mm*216mm*287mm
10.2 kg
230Vac/50Hz, 110Vac/50Hz
2pcs of batteries for emergency
operation, 1.2A each, 1.1kg
6A, 24V
433.92MHz; 200 transmitters memory
24Vdc motor with mechanical release
Worm gear
10500N
10000N
24Vdc
2.5A
5.5A for maximum 10 seconds.
1000 kg per leaf
12 meters
20%
-20℃~+50℃
333mm*216mm*287mm
10.4 kg
230Vac/50 Hz , 110Vac/50Hz
2pcs of batteries for emergency
operation, 1.2A each, 1.1kg
11.4A, 22V
433.92MHz; 200 transmitters memory
PL600 PL1000
8.2 PH-1 Photocells
Detection type
Operating distance
Response time
Input voltage
Operating Temperature
Protection class
Dimension
Through beam
30 meters
100ms
AC/DC 12~24V
-20℃~+60℃
IP66
59mm * 87mm * 38mm
