Version 1.3-130603
14
low-input voltage warnings and shutdowns. This is due to the DC voltage
drop in the cables from the battery to the inverter.
The longer and narrower the cables, the greater the voltage drops.
WARNING!
DC wiring terminations.
Ensure all the DC connections and terminations are
secure and tight. Loose connection can cause
overheating and fire.
The following table recommends the cable size for optimum inverter
performance.
SU Series Wire AWG Inline Fuse Description
MI5703 #12 25A
Black 1M + Red 1M
MI5702 #10 25A*2
MI5704 #6 30A*4
MI5712
#4
25A*6
MI5710 #1 25A*12
Lay the flexible earth cable from the earthing point of the vehicle to the
earthing point of the inverter.
If cables are to be fed through metal walls or walls with sharp edges, use
glands or proper bushings to prevent cable damage.
Do not lay cables that are loose or bent next to electrically conductive
materials.
