PowerTech MI5700 User Manual

Version 1.3-130603
2
1. Specifications:
MODEL:
MI5700 MI5702 MI5703 MI5704 MI5706 MI5708 MI5710 MI5712
OUTPUT
Continuous output 180W 360W 800W 1100W 1500W 2000W
Surge 360W 720W 1600W 2200W 3000W 4000W
Voltage AC230V
Frequency 50Hz
Waveform Pure Sine Wave(THD<3%)
Regulation (Typ.) Vrms <±3%
USB Output (Typ.) DC 5V ± 5% 500mA
INPUT
Battery Voltage 12V 24V 12V 24V
DC Current (Typ.) 20A 40A 20A 80A 120A 160A 220A 110A
Low Battery Alarm 10.6±0.2V 21.2±0.3V 10.6±0.2V 21.2±0.3V
Low Battery Protection 10±0.2V 20±0.3V 10±0.2V 20±0.3V
High Battery Protection
15±0.2V 30±0.3V 15±0.2V 30±0.3V
No Load Current 0.35A 0.4A 0.2A 0.5A 0.75A 0.85A 0.95A 0.5A
Stand-by Current 0.08A 0.1A 0.05A 0.15A 0.18A 0.2A 0.2A 0.15A
Efficiency (Typ.) 89% 90% 92% 91% 91% 91% 91% 93%
Protection
High Temperature ; Short-Circuit ; Over Load ; Input Voltage
Load
Control
Load 95~100%
Alarm but remain working
Load 105%
Alarm then after 1 minute shut down
Load 120%
Alarm then after 5 seconds shut down
Operating temperature range
-20℃ ~ 40℃
Operation Humidity
20 ~ 90% RH
Storage Temp Humidity
-30℃ ~ 70℃, 10~90% RH
Intelligent Design Heat Auto
Control
Fans slow speeding up 38℃±3,Fans start speeding up:42℃±3
High Temperature Shut Down : 65℃±3，Restart Output: 56℃±3
Indicator
Inverter : Green LED / Over Load : Red LED / Over Temperature : Yellow LED
Others
Soft Start-up
Soft Started Function
Remote Controller
NO YES
Mechanical
D*W*H(mm)
186x117x57 230x118x57 295x165x57 364x180x74 350x230x74 450x230x74
Weight(kg)
0.85kg 1.05kg 1.9kg 3.6kg 4.2kg 5.5kg
Note
Efficency test done at approx 75% load, with 13V input for 12V model, 26V input for 24V model
Note: The specifications are subject to change without prior notice.
