GARAGE DOOR OPENERS USER MANUAL
4
Front hold
bracket
Iron rail x3 Rear pulley
bracket
Front pulley
bracket
Metal Chain Slide block Release Rope
Release trolley
Blocker x1
Motor
hold bracket x2
Ceiling
hold bracket
Header bracket Door bracket Ceiling bracket Curved
door arm
Straght
door arm
Junction x2 Ceiling support bracket
3. Installation
3.1 Inventory of a garage door opener
1
13
EXT- EXT+ LIT-
LIT+
PB GND GND +BATT
PH
+24V
1
Key Selector Push ButtonFlashing Light TX1 RX1 Battery
1 2
2
3
3
4
4
5
5
6
6
25
108
4
17 18 19 20
21
22 23 24
2
3
26
6 7
9
11
12
5
16
14
15
Hardware Inventory Optional for 1pcs x 1M Rail
M8*20
HEX bolt
x4
Metric bolt x2
M6*14
HEX bolt
x4
M8*8 Nut x6 M6*6 Nut x8
Clevis Pin x2
R-type pin x2
Self-tapping
screws
x4
