1.
SUMMARY
VLCD7 is a special LCD instrument designed for electric bicycles, which is
used to display the vehicle's driving speed, total mileage, single mileage,
batterypowerandsetthemotorpowergear,wheeldiameter,etc.,aswellas
optional wireless bluetooth function, which can display and adjust system
parametersthroughmobilephones.

2. SPECIFICATIONS
3. APPEARANCE
型号
VLCD7
Workingvoltage DC11V‐60V
Working current 70mA(15V)10mA(60V)
Display type Segment code LCD display
handlebar
diameterΦ22.2mm
Working temperature ‐10
0
C—+60
0
C
backlight WhiteLEDbacklightmode,brightness200cd/m
2

Overall dimensions 54mm×36mm×27mm
Waterproof level IP65
