4. FUNCTION DESCRIPTION
1）Speeddisplay‐‐‐displaysactualcyclingspeedinkilometers(km/h)and
miles(omitted).
2）Batteryleveldisplay‐‐‐‐horizontal4‐segmentdisplayisadopted.Full
brightnessof4segmentsindicatesfullpower.Flickerofthelastsegment
indicatesthatthebatteryisoutofpowerandremindstheusertocharge.
3）One‐waymileage‐‐‐displayssingledrivingmileage,whichcanbereset
manually.
4）Total
mileage‐‐‐‐displaysaccumulatedmileage..
5）Averagespeeddisplay‐displaystheaveragespeedinasinglerange
.6）Powergearselection‐‐‐4powerselection.
7）Wheeldiameterselection‐‐switchwheeldiameter5‐35inches,factory
default26inches.
8）Speedsensormagneticsteelnumberselection‐‐speedsensormagnetic
steelnumber1‐15optional,factorydefault1magneticsteel.
9）Choiceofspeedunits‐metricandimperialareoptional.
10）6Km/hboostfunction‐‐‐‐canbeturnedOFForenabled6Km/hboost
function,factorydefaultOFF.
11）Topspeedlimitselection‐‐‐‐adjustthesizeoftopspeedlimit10‐60
Km/h,thedefaultis25Km/h..
12）Wirelessbluetoothfunction:itcanconnectwiththemobilephoneto
achievemorefunctions.
13）Faultdiagnosis
‐‐automaticallydisplaysthefaultdiagnosiscode.
5. OPERATION METHOD
5.1. Panel definition
