Specifications
36
Powerware
®
9120 User's Guide  05147426 A Uncontrolled Copy
Table 8. Battery
Configuration 700 VA: (2) 12V, 7 Ah internal batteries; 24 Vdc
1000 VA: (3) 12V, 7 Ah internal batteries; 36 Vdc
1500 VA: (4) 12V, 7 Ah internal batteries; 48 Vdc
20003000 VA: (8) 12V, 7 Ah internal batteries; 96 Vdc
EBM Configuration
PW9120 BAT-700: (4) 12V, 27 Ah; 24 Vdc
PW9120 BAT-1000: (6) 12V, 27 Ah; 36 Vdc
PW9120 BAT-1500: (8) 12V, 27 Ah; 48 Vdc
PW9120 BAT-3000: (16) 12V, 27 Ah; 96 Vdc
Type Sealed, maintenancefree, valveregulated, leadacid
Charging Approximately 4 hours to 90% usable capacity at nominal line voltage after full load discharge
Table 9. Battery Run Times (in Minutes)
Number of Batteries
Run Times at Full/Half Load by UPS VA Ratings
Number of Batteries
700 VA 1000 VA 1500 VA 2000 VA 3000 VA
UPS Internal Batteries 7/18 7/18 7/18 12/34 6/15
1 EBM 34/70 36/80 29/67 49/107 30/70
2 EBMs 64/140 66/155 56/130 93/195 58/128
3 EBMs 141/310 87/191
4 EBMs 192/403 120/264
5 EBMs 240/504 148/325
NOTE Battery times are approximate and vary depending on the load configuration and battery charge.
