UPS Startup
24
Powerware
®
FERRUPS FE/QFE UPS (500 VA–18 kVA) User’s Guide : Rev A www.powerware.com
RS-232
Communication
Port
ON/OFF Switch
Output
Receptacles
Alarm Silence
Switch
Figure 5. FERRUPS 1.8–3.1 kVA Rear Panel
RS-232
Communication Port
4.3–5.3 kVA Models 7–18 kVA Models
RS-232
Communication Port
Receptacle Panel
(Optional for 7 kVA)
Optional Receptacle
Panel
Figure 6. FERRUPS 4.3–18 kVA Rear Panels
