HEMNVx & HEMSL Range Users, Installation & Servicing Instructions Doc Ref M103 issue 3.1 Feb 2018.
Injector Sizes & Burner Pressures - Propane G31 Net CV (Hi = 88.00MJ/m³
(Max) (Min)
Injectors
Burner
Pressure
Gas Rate
Burner
Pressure
Gas Rate
MODEL No. Size (mm)
Marked mbar m³/h mbar m³/h
HEMNVx 10-3 3 1.1 tba 23.9 0.45 9.0 0.28
HEMNVx 15-4 4 1.15 tba 25.3 0.67 7.9 0.38
HEMNVx 18-5 5 1.15 tba 23.3 0.81 8.8 0.49
HEMNVx 25-5 5 1.36 240 23.0 1.12 10.0 0.74
HEMNVx 30-6 6 1.36 240 22.9 1.35 8.6 0.83
HEMNVx 40-8 8 1.36 240 22.9 1.80 8.4 1.09
HEMNVx 50-6 6 1.75 500 23.2 2.25 7.5 1.28
HEMNVx 60-7 7 1.75 500 24.5 2.70 8.2 1.47
HEMNVx 75-9 9 1.75 500 23.2 3.37 8.5 1.92
HEMNVx 100-12 12 1.75 500 23.2 4.50 8.7 2.76
HEMNVx 110-13 7+6 1.75 500 23.9 4.95 9.0 3.03
HEMNVx 125-15 9+6 1.75 500 23.2 5.62 8.7 3.45
HEMNVx 150-18 9+9 1.75 500 23.2 6.74 8.7 4.14
HEMNVx 175-21 12+9 1.75 500 23.2 7. 87 8.7 4.82
HEMNVx 200-24 12+12 1.75 500 23.2
8.99 8.7 5.51
(Max) (Min)
Injectors
Burner
Pressure
Gas Rate
Burner
Pressure
Gas Rate
MODEL No. Size (mm)
Marked mbar m³/h mbar m³/h
HEMSL 30-6 6 1.36 240 20.5 1.36 6.5 0.76
HEMSL 45-9 9 1.36 240 20.4 2.04 6.4 1.15
HEMSL 50-6 6 1.94 500 14.6 2.27 3.9 1.18
HEMSL 60-12 12 1.36 240 19.5 2.73 4.9 1.36
HEMSL 75-9 9 1.94 500 14.8 3.41 4.0 1.77
HEMSL 75-15 6+9 1.36 240 20.2 3.41 5.5 1.77
HEMSL 90-18 9+9 1.36 240 20.5 4.09 7.4 2.45
HEMSL 100-12 12 1.94 500 14.8 4.54 4.6 2.54
HEMSL 125-15 6+9 1.94 500 14.6 5.68 4.6 3.18
HEMSL 150-18 9+9 1.94 500 16.0 6.97 5.0 3.90
HEMSL 175-21 9+12 1.94 500 15.2 8.07 4.8 4.50
HEMSL 200-24 12+12 1.94 500 15.0 9.19 4.7 5.14
Minimum Inlet Pressure = 37mbar
Maximum Inlet Pressure = 60mbar
