HEMNVx & HEMSL Range Users, Installation & Servicing Instructions Doc Ref M103 issue 3.1 Feb 2018.
(Max) (Min)
Injectors
Burner
Pressure
Gas Rate
(nominal)
Burner
Pressure
Gas Rate
(nominal)
MODEL No. Size (mm)
Marked mbar m³/h mbar m³/h
HEMNVx 10-3 3 1.67 380 10.7 1.16 3.2 0.63
HEMNVx 15-4 4 1.67 380 13.6 1.74 4.1 0.95
HEMNVx 18-5 5 1.67 380 10.7 2.09 3.2 1.15
HEMNVx 25-5 5 1.94 500 13.3 2.91 4.0 1.60
HEMNVx 30-6 6 1.94 500 13.6 3.49 4.1 1.92
HEMNVx 40-8 8 1.94 500 13.2 4.65 4.0 2.56
HEMNVx 50-6 6 2.54 750 12.6 5.87 3.8 3.19
HEMNVx 60-7 7 2.54 750 12.8 7.05 3.9 3.84
HEMNVx 75-9 9 2.54 750 12.5 8.91 3.8 4.79
HEMNVx 100-12 12 2.54 750 12.7 11.75 3.8 6.39
HEMNVx 110-13 7+6 2.54 750 12.9 12.79 3.9 7.03
HEMNVx 125-15 9+6 2.54 750 12.5 14.45 3.8 7.99
HEMNVx 150-18 9+9 2.54 750 12.5 17.69 3.8 9.59
HEMNVx 175-21 12+9 2.54 750 12.5 20.33 3.8 11.19
HEMNVx 200-24
12+12 2.54 750 12.5 23.60 3.8 12.78
Injector Sizes & Burner Pressures - Natural Gas - Group H - G20 Net CV (Hi = 34.02MJ/m³
Minimum Inlet Pressure = 20.0mbar
Maximum Inlet Pressure = 60mbar
(Max) (Min)
Injectors
Burner
Pressure
Gas Rate
(nominal)
Burner
Pressure
Gas Rate
(nominal)
MODEL No. Size (mm)
Marked mbar m³/h mbar m³/h
HEMSL 30-6 6 1.94 500 13.8 3.53 4.4 1.99
HEMSL 45-9 9 1.94 500 13.4 5.29 4.6 3.16
HEMSL 50-6 6 2.54 750 12.3 5.88 3.7 3.20
HEMSL 60-12 12 1.94 500 13.6 7.05 3.2 3.40
HEMSL 75-9 9 2.54 750 12.5 8.82 4.9 5.54
HEMSL 75-15 15 1.94 500 13.6 8.82 5.4 5.54
HEMSL 90-18 18 1.94 500 13.7 10.58 5.2 6.51
HEMSL 100-12 12 2.54 750 12.7 11.76 4.3 6.86
HEMSL 125-15 15 2.54 750 12.3 14.70 4.2 8.58
HEMSL 150-18 18 2.54 750 13.4 18.04 4.6 10.53
HEMSL 175-21 21 2.54 750 12.6 20.81 4.3 12.14
HEMSL 200-24 24 2.54 750 13.3 23.78 4.5 13.88
HEM-SL
HEM-NVx
1.2 Technical Data
