Natural Gas to Propane (LPG) Conversion Data
Nominal Inlet Pressure = 37mbar, Minimum Inlet Pressure = 37mbar
High Fire Low Fire
Injectors
Burner
Pressure
Burner
Pressure
MODEL
Conversion Kit
part number
No. Size (mm)
Marked
Injector part
number
mbar mbar
LNVx15 NVx15LPG 4 1.36 240 142401661 21.3 8.0
LNVx20 NVx20LPG 4 1.36 240 142401661 19.8 9.2
LNVx25 NVx25LPG 5 1.36 240 142401661 21.3 10.2
LNVx35 NVx35LPG 7 1.60 160 142401678 22.5 11.5
LNVx40 NVx40LPG 8 1.36 240 142401661 19.5 25.8
LNVx45 NVx50LPG 10 1.6 160 142401678 18.4 29.3
LNVx50 NVx50LPG 10 1.6 160 142401678 24.2 12.2
LNVx60 NVx60LPG 8 1.6 160 142401678 25.4 12.3
LNVx70 NVx75LPG 10 1.6 160 142401678 22.9 11.5
LNVx90 NVx90SFLPG 8 2.26 580 142401667 13.5 7.2
LNVx120 NVx120SFLPG 10 2.26 580 142401667 14.6 7.2
LNVx140 NVx140SFLPG 12 2.26 580 142401667 13.4 6.4
Propane (LPG) to Natural Gas Conversion Data
Nominal Inlet Pressure = 20mbar, Minimum Inlet Pressure = 17.5mbar
High Fire Low Fire
Injectors
Burner
Pressure
Burner
Pressure
MODEL
Conversion Kit
part number
No. Size (mm)
Marked
Injector part
number
mbar mbar
LNVx15 NVx15NG 4 1.94 500 142401664 13.1 5.0
LNVx20 NVx20NG 4 1.94 500 142401664 12.3 6.0
LNVx25 NVx25NG 5 1.94 500 142401664 13.5 6.5
LNVx35 NVx35NG 7 2.54 750 142401665 13.2 6.8
LNVx40 NVx40NG 8 1.94 500 142401664 12.3 6.0
LNVx45 NVx50NG 10 2.54 750 142401665 7.4 3.5
LNVx50 NVx50NG 10 2.54 750 142401665 9.5 4.5
LNVx60 NVx60NG 8 2.54 750 142401665 10.6 5.2
LNVx70 NVx75NG 10 2.54 750 142401665 9.4 4.6
LNVx90 NVx90NG 8 3.5 1500 142401666 6.0 3.0
LNVx120 NVx120NG 10 3.5 1500 142401666 6.7 3.3
LNVx140 NVx140NG 12 3.5 1500 142401666 6.2 2.9
