2 / 16
Power rating
Output
power
(kW)
Dimension
(mm)
Installation
(mm)
Power
rating
H
H1
W
D
D1
A
B
d
PI500A 0R4G1
0.4
163
185
90
146
154
65
174
5
1.6
PI500A 0R4G2
0.4
PI500A 0R7G1
0.75
PI500A 0R7G2
0.75
PI500A 0R7G3
0.75
PI500A 0R7G4
0.75
PI500A 1R5G2
1.5
PI500A 1R5G3
1.5
PI500A 1R5G4
1.5
PI500A 2R2G3
2.2
PI500A 2R2G4
2.2
PI500A 1R5G1
1.5
163
185
90
166
174
65
174
5
1.8
PI500A 2R2G1
2.2
PI500A 2R2G2
2.2
PI500A 004G3
4
PI500A 004G4
4
PI500A 004G1
4
238
260
120
182
190
90
250
5
2.7
PI500A 004G2
4
PI500A 5R5G2
5.5
PI500A 5R5G3
5.5
PI500A 5R5G4
5.5
PI500A 7R5G3
7.5
PI500A 7R5G4
7.5
PI500A 011F3
11
PI500A 011G3
11
PI500A 011F4
11
PI500A 011G4
11
PI500 5R5G1
5.5
290
/
170
193
201
155
276
5
5.8
PI500 7R5G1
7.5
PI500 7R5G2
7.5
PI500 011G2
11
PI500 015F3
15
PI500 015G3/PI500 018F3
15/18.5
PI500 018G3/PI500 022F3
18.5/22
PI500 022G3
22
PI500 015F4
15
PI500 015G4/PI500 018F4
15/18.5
PI500 018G4/PI500 022F4
18.5/22
PI500 022G4
22
4. Keyboard description
Operation panel display
4.1 Keyboard Indicators
Indicator flag
Name
Status
lamp
RUN
Running indicator light
*ON:the inverter is working
*OFF:the inverter stops
LOCAL/
REMOTE
Command indicator light
That is the indicator for keyboard operation, terminal operation and remote
operation(Communication contral)
*ON:terminal control working status
*OFF:keyboard control working status
*Flashing:remote control working status
FWD/REV
Forward/reverse running light
*ON:in forward status
*OFF:in reversal status
TUNE/TC
Motor self-learning/Torque control/Fault indicator
*Slow flashing:in the motor tunning status
*Quick flashing:in the fault status
Units
combination
indicator
HzAV
Hz
Frequency unit
A
Current unit
V
Voltage unit
RPM
Speed unit
%
percentage
4.2 Description of operation panel keys
Sign
Name
Function
Parameter
Setting/Esc Key
* Enter into the modified status of main menu
* Esc from functional parameter modification
* Esc submenu or functional menu to status menu
Shift Key
* Choose displayed parameter circularly under running or stop
interface;choose parameter’s modified position when modify parameter
Increasing Key
* Parameter or function number increasing, set by parameter F6.18.
Decreasing Key
* Parameter or function number increasing, set by parameter F6.19.
Running Key
* For starting running in the mode of keyboard control status
Stop/Reset Key
* For stopping running in the running status;for resettingthe operation
in the fault alarm status .The function of the key is subject to F6.00
