Remaining run time
Remaining run time display, it is for timing run control
0.1Min
Linear speed
Show the line speed of DI5 high speed pulse sampling,
according to the actual sample pulse number per minute
and E0.07, calculate the line speed value.
1m/Min
Current power-on time
Total time of current inverter power-on
1Min
Current run time
Total time of current inverter run
0.1Min
HDI(DI5) impulse frequency
HDI(DI5) high-speed impulse input frequency display,
unit: 1Hz
1Hz
Communication set value
Frequency, torque or other command values set by
communication port
0.01%
Master frequency setting
display
Frequency set by F0.03 master frequency setting source
0.01Hz
Auxiliary frequency setting
display
Frequency set by F0.04 auxiliary frequency setting
source
0.01Hz
Inverter status
Display the running and standby etc status information
-
Inverter type
1:G type: Suitable for constant torque load;
2:F type: Suitable for variable torque load (Fans, pumps
load)
-
AI1 voltage before correction
Input voltage value before linear correction of AI1
0.01V
F0 group Basic function group
Code
Parameter name
Setting range
Factory
setting
Cha
nge
F0.00
Motor control mode
0:Vector control without PG
2:V/F control
2
F0.01
Keyboard set frequency
0.00Hz to F0.19(Maximum frequency)
50.00Hz
F0.02
Frequency command
resolution
1: 0.1Hz
2: 0.01Hz
2
F0.03
Frequency source master
setting
0: Keyboard set frequency (F0.01, UP/DOWN can be
modified, power-down without memory)
1: Keyboard set frequency (F0.01, UP/DOWN can be
modified, power-down with memory)
2: Analog AI1 setting;4: Panel potentiometer setting
5:High-speed pulse setting;
6: Multi-speed operation setting
7: Simple PLC program setting;
8: PID control setting;
9:Remote communications setting
1
F0.04
Frequency source
auxiliary setting
Same as F0.03 setting
0
F0.05
Reference object selection
for frequency source
auxiliary setting
0. Relative to maximum frequency;
1. Relative to master frequency source 1
2. Relative to master frequency source 2
0
F0.06
Frequency source
auxiliary setting range
0% to 150%
100%
F0.07
Frequency superimposed
selection
Units digit: Frequency source selection;
Tens digit: Arithmetic relationship of master and
auxiliary for frequency source
00
F0.08
Frequency source offset
frequency when
superimposing
0.00Hz to F0.19(Maximum frequency)
0.00Hz
F0.09
Shutdown memory
selection for digital set
frequency
0: W/O memory;
1: With memory
1
F0.10
UP/DOWN standard
0: Running frequency ;
1: Set frequency
0
F0.11
Command source
selection
0. Keyboard control (LED off);
1. Terminal block control (LED on)
2. Communications command control (LED flashes)
3. Keyboard control+ Communications command
control
4. Keyboard control+ Communications command
control+ Terminal block control
0
F0.12
Binding frequency source
for command source
Units digit: Keyboard command binding frequency
source selection
0:Not binded;
1: Keyboard set frequency;
2:AI1 setting;
4:Panel potentiometer setting;
5:High-speed pulse setting;
6:Multi-speed setting
7:Simple PLC setting;
8:PID setting;
9:Communications reference
Tens digit: Terminal block command binding
frequency source selection (0 to 9, same as units
digit)
Hundreds digit: Communication command binding
frequency source selection (0 to 9, same as units
digit)
000
F0.13
Acceleration time 1
0.0s to 6500s
Depend
on type
F0.14
Deceleration time 1
0.0s to 6500s
Depend
on type
F0.15
Ac/Deceleration time unit
0:1s;
1:0.1s;
2:0.01s
1
F0.16
Ac/deceleration time
reference frequency
0:F0.19(Maximum frequency)
1:Set frequency;
2:100Hz
0
F0.17
Carrier frequency
adjustment as per
temperature
0:NO ;
1: YES
0
F0.18
Carrier Frequency
0.5kHz to 16.0kHz
Depend
on type
F0.19
Maximum output
frequency
50.00Hz to 320.00Hz
50.00Hz
F0.20
Upper limit frequency
source
0:F0.21 setting;
1:AI1 setting;
3:Panel potentiometer setting;
4: High-speed pulse setting;
5: Communications reference
0
F0.21
Upper limit frequency
F0.23 (Lower limit frequency) to F0.19 (Maximum
frequency)
50.00Hz
F0.22
Upper limit frequency
0.00Hz to F0.19 (Maximum frequency)
0.00Hz
