Section IV Main circuit and terminal wiring
 PR5200(C) series soft starter has two kinds of wiring:
The main circuit wiring: three phase power input and output to the motor wiring
and coil in line circuit breaker, bypass contactor wiring.
External terminal wiring: by 14 small terminals derivation, including input, output
control lines and analog output signal lines.
4-1. The basic wiring diagram of the soft starter
4-2. Instruction of soft starter terminal wiring.
Output terminal like chart 4.2 illustration：
PR5200 Series
Soft Starter
3phase power input
Keyboard
control
M
3phase asynchronous mouse cage motor
Braker(QF)
chart
4.1
Connector(KM)
Note：six copper bar， below 3 for motor，upper 3 for contactor
