3
2. Wall M
ounting
Please refer to the antenna mounting
precautions before proceeding with the
installation.
• Select a suitable place for mounting the
antenna.
• Use a 6mm masonry drill bit to drill four
holes into the wall. See the dimensions
below.
• Mount the Z-Bracket to the wall using 4 x
6mm wall plug screws (Not included).
• Attach 4 x M6x12mm hex bolts and
washers through the backing plate, Z-
bracket, onto the back of the antenna.
• Use a spanner to fasten the bolts.
3
