PPA DZ HOME User Manual

15
MAGNET SUPORT
REED SUPORT
UPPER VIEW
BRACKET
ADJUSTMENT
BRACKET
ADJUSTMENT
3º Step: Start the engine and
see if the REED's are shutting
off properly. If necessary,
invert the connector on the
board.
After attaching the magnet
holders, make final
adjustments by moving to
the right or left, depending
on the desired setting.
4º Step: To finalize the installation of the
operator, it is mandatory before screwing the
fairing with 2 x 3.5 x 16 mm screws (available
in the kit).
