TOOLS REQUIRED FOR INSTALLATION

Here are some tools required to install the operator:

ELECTRICAL INSTALLATION

For electrical installation, the network shall contain the following characteristics:

- Electric network 127V or 220V;

- Have 5A circuit breakers in the electrical distribution box;

- 3/4 "diameter conduit between the electrical distribution box and the total

disconnect device;

- 3/4 "diameter conduit between the total shut-off device and the operator

connection point;

- 1/2 "diameter conduits for buttonhole, external and optional;

- 1/2 "diameter for safety photocells (optional).

PLIERS

SAWING BOW SOCKET WRENCH SCREWDRIVER NUT WRENCH

LADDER

WELDING MACHINE HAMMER LEVEL TAPE MEASURE

FRAME DRILL PENCIL SANDER

- The cable for the fixed wiring must comply with NBR NM 247-3;

-The power conductor of a product for internal use must be a

flexible cable 3 x 0.75 mm²; 500 V, according to the norm NBR

NM 247-5;

-The power conductor of a product for external use must be a

3 x 0.75 mm² flexible cable; 500 V, according to IEC 60245-57.
