4
DZ HOME
OPERATOR TYPE SLIDING SLIDING SLIDING
RATED VOLTAGE 220 V 220 V 127 V
NOMINAL FREQUENCY 60 Hz 50 Hz 60 Hz
RATED POWER 460 W 470 W 335 W
MOTOR ROTATION 1740 rpm 1455 rpm 1740 rpm
NOMINAL CHAIN 2,15 A 2,37 A 2,86 A
REDUCTION 1:24 1:24 1:24
LINEAR SPEED 16,4 m/min 13,7 m/min 16,4 m/min
PERFORMANCE 30 cycles/h 30 cycles/h 30 cycles/h
DEGREE PROTECTION IPX 4 IPX 4 IPX 4
TEMPERATURE RANGE -5° C / +50° C -5° C / +50° C -5° C / +50° C
ISOLATION TYPE Class B, 130 ° C Class B, 130 ° C Class B, 130 ° C
LIMIT SWITCH ANALOG ANALOG ANALOG
DZ HOME JET FLEX / DZ HOME BLDC
OPERATOR TYPE BLDC SLIDING JET FLEX SLIDING
RATED VOLTAGE 220 V / 127 V 220 V / 127 V
NOMINAL FREQUENCY 60 Hz 60 Hz
RATED POWER 100W / 130W 100W / 130W
MOTOR ROTATION 4500 rpm 4365 RPM
NOMINAL CHAIN 0,7A / 1,4A 2,75 A / 3,6 A
REDUCTION 1:22 1:22
LINEAR SPEED 36 m/min 41 m/min
PERFORMANCE 100 cycles/h 40 cycles/h
DEGREE PROTECTION IPX 4 IPX 4
TEMPERATURE RANGE -5° C / +50° C -5° C / +50° C
ISOLATION TYPE Class B, 130 ° C Class B, 130 ° C
LIMIT SWITCH Hybrid Hybrid
MAX. MASS FROM THE
GATE LEAF
400kg 400kg
MAXIMUM DIMENSION;
GATE
HEIGHT = 2,5 m LENGTH
= 3,0 m
HEIGHT = 2,5 m LENGTH
= 3,0 m
TECHNICAL CHARACTERISTICS
