PPS RPS125S User Manual

6
MAIN DATA
ENGINE
DESCRIPTION 110 series 125 series
Engine Type Single cylinder, air cooled, four stroke, horizontal machine
Displacement (ml) 106.693 124
Bore×Stroke (mm) 52.4×49.5 54×54
Compression Ratio 9:0:1 9:0:1
Max. Power (kw/r/min) 5.0kW/7500rpm 6.0kW/7500rpm
Max. Torque (N.m/r/min) 7.5N.m/5500rpm 9.5N.m/5500rpm
Max. Speed (Km/h) 80 80
Lubrication Pressure, splash
Clutch Type Manual / wet
Ignition CDI
Starting System Kick Start
Transmission System Chain
CHASSIS
DESCRIPTION 110 series 125 series
Front Brake Disk
Front Brake Disc
Front Tire 2.50-14 70/110-17
Rear Tire 3.00-12 90/100-14
DIMENSIONS
DESCRIPTION 110 series 125 series
L*W*H (mm) 1625*780*1030 1770*780*1065
Seat Height (mm) 775 810
Wheelbase (mm) 1210
Min. Ground Clearance
(mm)
150 190
Max. Permissionable Weight
(kg)
75 80
Engine Oil (L) 0.9 1.0
Fuel Tank Capacity (L) 6.1 6.1

PPS RPS125S Specifications

General

Brand	PPS
Model	RPS125S
Category	Bicycle
Language	English
