PR electronics 5333 - Input and Output Details; RTD and Linear Resistance Input; Output Current Specifications; Sensor Error Detection Methods

5333V111-UK 5
Effect of supply voltage variation .................... ≤ 0,005% of span / VDC
Vibration ...................................................................... IEC 60068-2-6 Test FC
 2...25Hz ..................................................................
±1.6 mm
 25...100Hz ...................................................... ±4 g
Max.wiresize ............................................................ 1 x 1.5 mm
2
stranded wire
Humidity ...................................................................... < 95% RH (non-cond.)
Dimensions ................................................................. Ø 44 x 20.2 mm
Protection degree (enclosure / terminal) ....... IP68 / IP00
Weight .......................................................................... 50 g
Electrical specifications, input:
RTD and linear resistance input:
Max. offset ................................................................. 50% of selec. max. value
Cable resistance per wire (max.) ....................... 10 Ω
Sensor current ........................................................... > 0.2 mA, < 0.4 mA
Effect of sensor cable resistance
(3-wire) ........................................................................ < 0.002 Ω / Ω
Sensor error detection ........................................... Yes
Output:
Current output:
Signal range ............................................................... 4...20 mA
Min. signal range ...................................................... 16 mA
Updating time ........................................................... 135 ms
Loadresistance......................................................... ≤ (V
supply
- 8) / 0.023 [Ω]
Loadstability ............................................................. < ±0.01% of span / 100 Ω
Sensor error detection:
Programmable ........................................................... 3.5...23 mA
NAMUR NE43 Upscale ........................................... 23 mA
NAMUR NE43 Downscale ..................................... 3.5 mA
Of span = Of the presently selected range
RTD
type
Min.
value
Max.
value
Min.
span Standard
Pt100
Ni100
Lin.R
-200°C
-60°C
0 Ω
+850°C
+250°C
10000 Ω
25°C
25°C
30 Ω
IEC 60751
DIN 43760
-----
