Nova manual.doc
5/12
Use the plug provided to connect the mains power to the projector paying attention to the
voltage and frequency marked on the panel of the projector. It is recommended that each
projector is supplied separately so that they may be individually switched on and off. It is
recommended that the green/yellow cord must be earthed correctly.
The projector may be controlled by sound, auto programmes or a controller, and it may be operated
in Stand-Alone automatic mode, in Master/Slave synchro mode or in Controller mode. With the touch-
switches and the digital display screen, DMX start address can be easily set and the various setup
options may be configured.
TO SET THE DMX START ADDRESS
The display shows the DMX start address after the
projector is switched on (if you have already set the
DMX start address and saved it, the screen will display
the last setting).
Press the UP or DOWN buttons to select the required
DMX start address in the display.
Confirm your choice by pressing the ENTER button.
The green LED will flash and the projector will save it.
In Stand-Alone mode, the DMX start address can be set at random.
In the Controller and Master/Slave mode, the DMX start address must be set correctly. (Refer to
“Controller mode” and “Master/Slave mode” sections).
SETUP OPTIONS - PROJECTOR CONFIGURATION
To browse through the various Setup Options, press the FUNC button consecutively. There are 11
option codes (1~9 and A, b), each code has a specific function. The functions provided are listed in
the following table.
Once you have selected the desired operation code, press the key UP or DOWN to select “y” (means
ON) or “n “ (means OFF). y = YES, n = NO.
Press the key ENTER to save the selected function and configuration. If the display is showing “y”,
then the setting has been enabled. In the same way, if it was showing “n” when you pressed ENTER
the option has been disabled.
The green LED will flash during this operation.
POWER SUPPLY - MAINS
OPERATION
