5725V101-IN 9
Electrical specifications
Environmental conditions:
Specifications range .................................... -20°C to +60°C
Storage temperature ................................... -40°C to +85°C
Calibration temperature............................... 20...28°C
Relative humidity ......................................... < 95% RH (non-cond.)
Protection degree ........................................ IP20
Installation in pollution degree 2 & overvoltage category II.
Mechanical specifications:
Dimensions (H x W x D) .............................. 48 x 96 x 120 mm
Cutout dimensions ...................................... 44.5 x 91.5 mm
Protection degree (mounted in panel) ......... IP65 / Type 4X, UL50E
Weight ......................................................... 230 g
Wire size, pin 11-12 & 41-44, max .............. 1 x 1.5 mm2/
AWG 30...16 stranded wire
Wire size, others, max ................................. 1 x 2.5 mm2/
AWG 30...12 stranded wire
Terminal connection .................................... Spring-cage
Common electrical specifications:
Supply voltage, universal ............................ 21.6...253 VAC, 50...60 Hz
or 19.2...300 VDC
Max consumption, 5725A / 5725D ............. 2.8 W / 3.6 W
Isolation voltage, test / operation ............... 2.3 kVAC / 250 VAC
Signal / noise ratio ...................................... > 60 dB
Order: 5725
Type Version
5725 Standard...................: A
Analogue output and 2 relays ..: D
8335 = Splash proof front
Accessories:
