PR 5725 User Manual

20 5725V101-IN
SCROLLING HELP TEXTS
Top line Scrolling text
TEXT NR
Language menu
UK UK - SELECT ENGLISH HELP TEXT
0
DK DK - VAELG DANSK HJAELPETEKST
1
DE DE - WAEHLE DEUTSCHEN HILFETEXT
2
FR FR - SELECTION TEXTE D’AIDE EN
FRANCAIS
3
SE SE - VALJ SVENSK HJALPTEXT
4
IT IT - SELEZIONARE TESTI DI AIUTO
ITALIANI
5
ES ES - SELECCIONAR TEXTO DE AYUDA
EN ESPANOL
6
CZ CZ - VYBER CESKOU NAPOVEDU
7
Error indication
(when active, labels are flashing @ app. 1 Hz)
SE.BR SENSOR WIRE BREAKAGE
8
IN.HI INPUT OVERRANGE
9
SE.SH SENSOR SHORT CIRCUIT
10
IN.LO INPUT UNDERRANGE
11
9.9.9.9. DISPLAY OVERRANGE
12
-1.9.9.9. DISPLAY UNDERRANGE
13
HW.ER HARDWARE ERROR
14
EE.ER EEPROM ERROR - CHECK
CONFIGURATION
15
RA.ER RAM MEMORY ERROR
16
NO.CA DEVICE NOT CALIBRATED
17
Fastset Menu
F.SET
REL1 FAST SET MENU - SELECT RELAY
18
REL2 FAST SET MENU - SELECT RELAY
18
SETP (if fastset is enabled)
xxxx RELAY SETPOINT - PRESS OK TO SAVE
19
SETP (if fastset is disabled)
xxxx RELAY SETPOINT - READ ONLY
20
Configuration setup
PASS
xxxx SET CORRECT PASSWORD
21
IN
PNP PNP SENSOR INPUT
22
NPN NPN SENSOR INPUT
23
TTL TTL SENSOR INPUT
24
NAMU NAMUR SENSOR INPUT
25
S0 S0 SENSOR INPUT
26
TACH TACHO SENSOR INPUT
27
XmA SPECIAL CURRENT SENSOR INPUT
28
XV SPECIAL VOLTAGE SENSOR INPUT
29
TR.LO (when special voltage input is selected)
xxxx SET LOW TRIGGER LEVEL IN VOLT
30
TR.LO (when special current input is selected)
xxxx SET LOW TRIGGER LEVEL IN mA
31
TR.HI (when special voltage input is selected)
xxxx SET HIGH TRIGGER LEVEL IN VOLT
32
TR.HI (when special current input is selected)
xxxx SET HIGH TRIGGER LEVEL IN mA
33
Z.IN (when special voltage input is selected)
HI.Z SET INPUT RESISTANCE HIGH
34
PL.UP SET INPUT PULL UP
35
PL.DN SET INPUT PULL DOWN
36
S.SUP (not when NAMUR or S0 input is selected)
xxxx SET SENSOR SUPPLY VOLTAGE
37
IN.UN
HZ SET INPUT UNIT FOR FREQUENCY
38
S SET INPUT UNIT FOR PERIOD TIME
39
IN.LO
xxxx SET INPUT RANGE LOW IN HZ
40
xxxx SET INPUT RANGE LOW IN KHZ
41
xxxx SET INPUT RANGE LOW IN S
42
xxxx SET INPUT RANGE LOW IN mS
43
IN.HI
xxxx SET INPUT RANGE HIGH IN HZ
44
xxxx SET INPUT RANGE HIGH IN KHZ
45
xxxx SET INPUT RANGE HIGH IN S
46
xxxx SET INPUT RANGE HIGH IN mS
47
FILT
NO ENABLE INPUT FILTER
48
YES ENABLE INPUT FILTER
48
DEC.P
1111 DECIMAL POINT POSITION
49
111.1 DECIMAL POINT POSITION
49
11.11 DECIMAL POINT POSITION
49
1.111 DECIMAL POINT POSITION
49
DI.LO
xxxx DISPLAY READOUT LOW
50
DI.HI
xxxx DISPLAY READOUT HIGH
51
