5725V101-IN 21
REL.U
PERC SET RELAY IN PERCENTAGE
52
DISP SET RELAY IN DISPLAY UNITS
53
REL1
OFF RELAY 1 DISABLED
54
SETP ENTER RELAY 1 SETUP
55
SKIP SKIP RELAY 1 SETUP
56
SETP
xxxx RELAY SETPOINT
57
ACT1
INCR ACTIVATE AT INCREASING SIGNAL
58
DECR ACTIVATE AT DECREASING SIGNAL
59
HYS1
xxxx RELAY HYSTERESIS
60
ERR1
HOLD HOLD RELAY AT ERROR
61
ACTI ACTIVATE RELAY AT ERROR
62
DEAC DEACTIVATE RELAY AT ERROR
63
NONE UNDEFINED STATUS AT ERROR
64
ON.DE
xxxx RELAY ON-DELAY IN SECONDS
65
OF.DE
xxxx RELAY OFF-DELAY IN SECONDS
66
REL2
OFF RELAY 2 DISABLED
67
SETP ENTER RELAY 2 SETUP
68
SKIP SKIP RELAY 2 SETUP
69
SETP
xxxx RELAY SETPOINT
57
ACT2
INCR ACTIVATE AT INCREASING SIGNAL
58
DECR ACTIVATE AT DECREASING SIGNAL
59
HYS2
xxxx RELAY HYSTERESIS
60
ERR2
HOLD HOLD RELAY AT ERROR
61
ACTI ACTIVATE RELAY AT ERROR
62
DEAC DEACTIVATE RELAY AT ERROR
63
NONE UNDEFINED STATUS AT ERROR
64
ON.DE
xxxx RELAY ON-DELAY IN SECONDS
65
OF.DE
xxxx RELAY OFF-DELAY IN SECONDS
66
PO.DE
xxxx RELAY POWER ON DELAY IN SECONDS
70
A.OUT
20-4 OUTPUT RANGE IN mA
71
20-0 OUTPUT RANGE IN mA
71
4-20 OUTPUT RANGE IN mA
71
0-20 OUTPUT RANGE IN mA
71
O.ERR
23mA NAMUR NE43 UPSCALE AT ERROR
72
3.5mA NAMUR NE43 DOWNSCALE AT ERROR
73
0mA DOWNSCALE AT ERROR
74
NONE UNDEFINED OUTPUT AT ERROR
75
RESP
xxxx ANALOG OUTPUT RESPONSE TIME IN
SECONDS
76
E.PAS
NO ENABLE PASSWORD PROTECTION
77
YES ENABLE PASSWORD PROTECTION
77
N.PAS (when password enabled)
xxxx SELECT NEW PASSWORD
78
