5725V101-IN 13
Sensor error indication, inside and outside range
Input ”out of range” indication
Valid measurement range: Out of range limit Display readout
F to I function:
0.001 Hz to 50 kHz
< 0.0009 Hz
- equals ”Low cut off time”
”0” or ”IN.LO” if 0% input
value is set different from ”0”
> 50.5 kHz ”IN.HI”
Period time function:
20 µs to 999.9 s
>1111 s (18 min. 31 sec.)
- equals ”Low cut off time”
”IN.LO”
< 19.8 µs ”IN.HI”
! Error indications in the display blink once a second. The help text explains the error.
Sensor error indication in 5725, only available for NAMUR input:
Condition
Out of range
limit
Relay
behaviour
Analogue
output value
Display
redaout
Sensor input
type = NAMUR
and sensor error
detection = ON
> 6.9 mA Set to user
defined value:
HOLD. ACTIVE.
DEACTIVE or NONE
Set to user-
defined value
(23, 0, 3.5 mA
or NONE)
”SE.SH”
< 0.1 mA ”SE.BR”
Display out of range Indication
Valid display value range: Out of range limit Display readout
-1999 to 9999
< -1999 ”-1.9.9.9.” - flashing
> 9999 ”9.9.9.9.” - flashing
Hardware error indication
Error explanation Error cause Display readout
Error in internal communication
(SPI etc.)
Permanent error in inter-
communication between
microcontrollers
”HW.ER”
Error in checksum test of the
configuration in RAM
Error in RAM ”RA.ER”
Error in checksum test of the
configuration in EEPROM
Error in EEPROM ”EE.ER”
Error in OK check or checksum
test of the calibration data in
FLASH
Error in FLASH or
Calibration has not been per-
formed or Calibration data in
FLASH are corrupt
”NO.CA”
