ENGLISH 20


Parallel
Forapplicationswhichrequirehighcurrent,modulescanbeconnectedinparallelandthe
overallcurrentwillbeequaltothesumofthecurrentsofeachpanel.

RISK
Parallel connections can be set only if modules voltage characteristics are
identical.Aparallelconnectionisallowedforupto3stringsasamaximum.Ifthe
installation requires a higher amount of parallel connected strings, then a
blockingdiodeevery3stringsisrequired.
NOTE
Modulesofastringmusthaveidenticalorientationandinclination.

Inverters


Invertersconvertdirectcurrentintoalternatingcurrent.Invertersofthelatestgeneration,thanks
to the MPPT (Maximum Power Point Tracker), optimize the production, even in situations of
weatherchangesorvariablesunlight.Toreducemismatchlossesandoptimizetheperformanceof
thesystem,converterswith2ormoreMPPTarepreferred.
