Turning the shaft, have the piston guide move forward so that the buffer, moving ahead, can expel the seal
support and the entire piston unit (pos.c, fig.170).
Extract the seal support unit and the buffering tool.
Remove the seal support bottom O-ring should it remain inside the pump casing (pos.c, fig.171).
Remove the spray rings from the piston guides (pos.c, fig.172).
fig. 170
1
fig. 171
1
fig. 172
1
