10
Series 321
4.4 Under-fl oor weighing
For weighing objects which, because of their size or shape, cannot be put in or on the balance.
• Remove the screw (14) on the underside of the balance.
• Place the balance over an opening.
• Hang the hook for under-bench weighing, to which the object can be secured, into the aperture (16) of the
metal casting (15).
kg
16
15
14
14 Screw
15 Metal casting
16 Aperture
