PM-1030V v5 2020-10 Copyright © 2020 Quality Machine Tools, LLC
Dimensions in millimeters
Ref Description Part
1 Tailstock quill Z1009
2 Leadscrew nut Z1008
3 Leadscrew Z1007
4 Key 4 x 4 x 15 Z1283
5 Quill slide key Z1010
6 Lock lever hub Z1285
7 Lock lever Z1286
8 Quill clamp sleeve Z1287
9 Oiler Φ6 Z1288
10 Tailstock body Z1289
11 Lock lever Z1290
12 Eccentric shaft Z1291
13 Screw M5 x 16 Z1292
15 Leadscrew ange Z1293
16 Graduated collar Z1294
17 Leaf spring Z1295
18 Handwheel Z1296
19 Washer M8 Z1297
20 Locknut Z1298
21 Handle bolt Z1299
22 Handle sleeve Z1300
23 Thrust bearing Z1301
24 Nut M10 Z1302
25 Washer Φ10 Z1303
26 Set screw M6 x 10 Z1304
27 Adjusting block Z1005
28 Screw M6 x 16 Z1306
29 Clamp bolt Z1307
30 Screw M8 x 25 Z1308
Ref Description Part
31 Tailstock base Z1309
32 O󰀨set label Z1310
33 Screw M8 x 30 Z1311
34 Screw M5 x 8 Z1312
35 Splash guard Z1313
36 Clamp plate Z1314
37 Threaded stud M12/M10 Z1315
38 Spring 13 x 1 x 62 Z1316
39 Washer Φ12 Z1317
40 Nut M12 Z1318
41 Nut M8 Z1319
42 Screw M8 x 30 Z1320
43 Washer Φ8 Z1321
44 Bed Z1322
45 Screw M5 x 10 Z1323
46 Rack locating pin Z1324
47 Rack Z1325
48 Label Z1326
49 Rivet Z1327
50 Washer Φ5 Z1328
51 Leadscrew 8TPI Z1329
52 Support block Z1330
53 Thrust bearing Z1331
54 Washer Φ15 Z1332
55 Nut M12 Z1333
56 Pin Φ6 x 25 Z1334
57 Screw M6 x 12 Z1335
58 Key 5 x 5 x 25 Z1336
59 Drive pin Z1337
BED & TAILSTOCK Fig 6
