Precision matthews PM-25MV

23
PM 25MV v9 2021-12 Copyright © 2021 Quality Machine Tools, LLC
Ref Description Part
1 Base Z5285
2 Gib, Y-axis Z5286
3 Gib adjust screw Z5287
4 Y-axis leadscrew Z5288
5 Key: at, 5 x 16 Z5289
6 Ball bearing: 51103 Z5290
7 Y-axis support ange Z5291
8 Screw: M8 x 20 skt hd Z5292
9 Graduated dial Z5293
10 Handwheel Z5294
11 Washer: at, M10 Z5295
12 Locknut: M10 Z5296
13 Handle Z5297
14 Leaf spring Z5298
15 Oiler: 6 Z5299
16 Saddle, X-Y Z5300
17 Friction pin Z5301
18 Lock handle: M8 thread Z5302
19 Stop/indicator block Z5303
20 Screw: M5 x 12 skt hd Z5304
21 X-axis leadscrew nut Z5305
22 Washer: at, M6 Z5306
23 Washer: lock, M6 Z5307
24 Screw: M6 x 20 skt hd Z5308
25 Screw: M5 x 20 skt hd Z5309
26 Screw: M6 x 40 skt hd Z5310
27 Y-axis leadscrew nut Z5311
28 Screw: M5 x 16 skt hd Z5312
29 Y-axis way cover (sti󰀨eners included) Z5313
30 Washer: at, M5 Z5314
31 Screw: M6 x 16 skt hd Z5315
32 Pin: taper, 6 x 25 Z5316
33 X-axis support ange: L Z5317
34 Table Z5318
35 Nut: square M6 Z5319
36 Screw: M6 x 12 skt hd Z5320
37 Stop collar Z5321
38 Table scale Z5322
39 X-axis leadscrew Z5323
40 X-axis support ange: R Z5324
Ref Description Part
41 Screw: M5 x 8 skt hd Z5325
42 Hose tting (coolant) Z5326
43 Z-axis pleated cover Z5327
44 Support bracket Z5328
45 Nut: M10 Z5329
46 Washer: lock, M10 Z5330
47 Washer: plain, M10 Z5331
48 T-bolt: M10 x 60 Z5332
49 Screw: M8 x 35 Z5333
50 Washer: lock, M 8 Z5334
51 Washer: plain, M 8 Z5335
52 Saddle, Z-axis Z5336
53 Z-axis leadscrew Z5337
54 Z-axis leadscrew nut Z5338
55 Washer: plain, M 12 Z5339
56 Pin: taper, 6 x 35 Z5340
57 Washer: lock, M 12 Z5341
58 Screw: M12 x 60 Z5342
59 Column Z5343
60 Column cap Z5344
61 Screw: M5 x 8 skt hd Z5345
62 Bevel gear A Z5346
63 Screw: M6 x 8, set Z5347
64 Pad Z5348
65 Key: at, 4 x 16 Z5349
66 Lifting gear shaft Z5350
67 Locknut: M12 Z5351
68 Washer: plain, M 12 Z5352
69 Collar Z5353
70 Graduated dial Z5354
71 Bevel gear B Z5355
72 Ball bearing: 51102 Z5356
73 Z leadscrew bracket Z5357
74 Screw: M5 x 14 Z5358
75 Z-axis scale Z5359
76 Washer Z5360
77 Gib, Z-axis Z5361
78 Tilt scale Z5362
79 Lock handle: swivel, M8 Z5363
80 Chip Tray (Not Pictured) Z7728
TABLE, COLUMN, & BASE COMPONENTS Fig 3
