Precision matthews PM 728V-T User Manual

20
PM 728V-T v2 2020-10 Copyright © 2020 Quality Machine Tools, LLC
Ref Description Part
1 Spindle cap Z5962
2 Draw bar Z5963
3 C-clip, spring cup retainer Z5964
4 Return spring cup Z5965
5 Return spring Z5966
6 Front plate Z5967
7 Spindle pulley Z5968
8 Bearing 6209ZZ Z5969
9 Spindle sleeve Z5970
10 Tach disk Z5971
11 Ball bearing 6007ZZ Z5972
12 Lock lever Z5973
13 DRO bracket Z5974
14 Sensor Z5975
15 Pin Z5976
16 Worm shaft Z5977
17 Knob Z5978
18 DRO back plate Z5979
19 DRO assembly Z5980
20 Scale bracket Z5981
21 Motor Z5982
22 Motor pulley Z5983
23 Belt Z5984
24 Motor base Z5985
25 Head casting Z5986
26 Set screw Z5987
27 Head tilting worm shaft Z5988
28 Pinion shaft Z5989
29 Worm wheel Z5990
30 Flange Z5991
31 Dial Z5992
32 Leaf spring Z5993
33 Clamp knob Z5994
34 Lever knob Z5995
35 Handle lever Z5996
36 Pinion shaft hub Z5997
37 O-ring Z5998
38 Spindle spline block Z5999
Ref Description Part
39 Ball bearing 6005ZZ Z6000
40 Quill Z6001
41 Bearing spacer Z6002
42 Ball bearing 7007 Z6003
43 Spindle Z6004
44 Bearing cover Z6005
45 Drawbar cover Z6006
47 Drive cover Z6007
48 Drive rear cover Z6008
49 Clamp screw Z6009
50 Clamp bracket Z6010
51 Hinge base Z6011
52 Cover hinge Z6012
806 Microswitch Z6013
901 Phl. hd. screw Z6014
902 Key Z6015
903 Set screw Z6016
904 Ext. retaining ring Z6017
905 Nut M3 Z6018
906 Screw Z6019
907 Cap screw Z6020
908 Phl. hd. screw Z6021
909 Cap screw Z6022
910 Nut Z6023
911 Cap screw Z6024
912 Lock washer Z6025
913 Washer Z6026
914 Key Z6027
915 Cap screw Z6028
916 Lock washer Z6029
917 Washer Z6030
918 Key Z6031
919 Cap screw Z6032
920 Cap screw Z6033
921 Phl. hd. screw Z6034
922 Nut Z6035
Model PM-728V-T HEADSTOCK & SPINDLE Fig 2
