Precision matthews PM 728V-T User Manual

22
PM 728V-T v2 2020-10 Copyright © 2020 Quality Machine Tools, LLC
Ref Description Part
12 Lock lever Z6036
101 Handle Z6037
102 Handwheel Z6038
103 Graduated dial Z6039
104 Thrust bearing 51202 Z6040
105 Leadscrew ange Z6041
106 Ball bearing 6002ZZ Z6042
107 Y-axis lead screw Z6043
108 Backing plate Z6044
109 Dovetail guard Z6045
110 Stop block Z6046
111 Gib adjustment screw Z6047
113 X-axis leadscrew nut Z6048
114 Gib Z6049
115 Y-axis leadscrew nut Z6050
116 Chip pan Z1011
117 Lock lever Z6052
118 Leadscrew cover A Z6053
119 Leadscrew cover B Z6054
120 Saddle Z6055
122 Head tilt worm wheel Z6056
123 T-bolt Z6057
126 Headstock base Z6058
128 Column cover Z6059
129 Column Z6060
130 Bevel gear Z6061
131 Z-axis gear bracket Z6062
132 Z-axis crank shaft Z6063
133 Hand wheel Z6064
134 Thrust bearing 51102 Z6065
135 Z-axis leadscrew Z6066
136 Leadscrew nut Z6067
137 Machine base Z6068
138 Table Z6069
139 Movable stop sleeve Z6070
Ref Description Part
140 Leadscrew ange Z6071
141 X-axis lead screw Z6072
142 Locking thumb screw Z6073
143 Way cover Z6074
903 Set screw Z6075
909 Cap screw Z6076
911 Cap screw Z6077
913 Washer Z6078
916 Lock washer Z6079
917 Washer Z6080
923 Nylon hex nut Z6081
924 Washer Z6082
925 Cap screw Z6083
926 Woodru󰀨 key Z6084
927 Phl. hd. screw Z6085
928 Cap screw Z6086
930 Washer Z6087
931 Cap screw Z6088
932 Cap screw Z6089
933 Cap screw Z6090
934 Set screw Z6091
935 Cap screw Z6092
936 Cap screw Z6093
937 Hex nut Z6094
938 Lock washer Z6095
939 Key Z6096
940 Retaining ring Z6097
941 Hex hd. bolt Z6098
942 Cap screw Z6099
943 Nut Z6100
L01 One-shot oiler Z6101
L02 Phl. hd. screw Z6102
L03 Screw Z6103
L04 Tubing Z6104
Model PM-728V-T TABLE & COLUMN Fig 3
