Table of contents
D 159195 © Precitec GmbH & Co. KG • EN 09/2019
v
Table of contents
1 Basic safety notes 1 - 1
1.1 Warranty and liability 1 - 1
1.2 Meaning of symbols and notes 1 - 1
1.3 Intended use 1 - 3
1.4 Basic standards 1 - 3
1.5 Obligations of operator and personnel 1 - 4
1.6 Normal operation safety measures 1 - 4
1.6.1 Protection against electric shock
1 - 4
1.6.2 Risk of injury from moving parts
1 - 5
1.6.3 Risk of injury from explosion
1 - 5
1.6.4 Risk of injury from laser radiation
1 - 5
1.6.5 Residual risk from uncontrolled laser beam escape
(angled laser head)
1 - 6
1.6.6 Corrosion in the water cooling circuit
1 - 6
1.6.7 Noise occurring during the laser cutting process
1 - 7
1.7 Storage and transport 1 - 7
1.8 What to do in emergency situations 1 - 7
2 Product description 2 - 8
2.1 Product - overall view 2 - 8
2.1.1 Design and functions
2 - 9
2.1.2 Distance controller
2 - 10
2.1.3 Protective equipment
2 - 10
2.2 Technical specifications 2 - 11
2.3 Specific versions
(focal lengths, collimators)
2 - 12
2.4 Straight versions
without protective window COL
(dimensions/ straight design)
2 - 13
2.4.1 Focal lengths 100/125
2 - 13
2.4.2 Focal length 150
2 - 14
2.4.3 Focal length 200
2 - 15
2.5 Straight versions
with protective window COL
(dimensions/ straight design)
2 - 16
2.5.1 Focal lengths 100/125
2 - 16
2.5.2 Focal length 150
2 - 17
2.5.3 Focal length 200
2 - 18
2.6 Angled versions
(dimensions, angled design)
2 - 19
2.7 Media connections 2 - 20
2.8 LightCutter 3D version 2 - 21
2.9 Accessories 2 - 22
2.9.1 Analysing electronics
(EG8030)
2 - 22
2.9.2 Optics service case
(storage box)
2 - 22
