Precor C954i User Manual

page 18
COMMERCIAL PRODUCTS DIVISION
Diagram 17
21
Raise or
lower the
deck.
14. Level the unit. Diagram 16. Check to make sure that the running deck is level
by taking the following steps:
a. Use a bubble level as shown in Diagram 16 to verify that the running deck is
level. If the treadmill is placed on a slightly, uneven surface, adjusting the
rear feet can help, but will not compensate for extremely uneven surfaces.
Important: If you need to make adjustments, adjust one rear foot at a time.
Do not use the rear foot to raise or lower the unit more than ¾-inches.
Adjustable
rear foot
Hand holds
on rear end
caps
Diagram 16
Adjust the level
of the treadmill.
Running belt
Bubble level
Adjustable rear
foot
b. Adjust the rear feet. Diagram 17. To raise the rear deck, situate yourself
next to the adjustable rear foot. Ask an assistant to lift the rear of the
treadmill slightly while you turn the adjustable rear foot clockwise. Turning
the rear foot counterclockwise lowers the unit.
c. Check the level of the unit after each adjustment. Make adjustments to the
rear feet so that both carry an equal amount of the treadmill’s weight and
the load placed upon it.
Important: If the load is not equally compensated, the user will feel exces-
sive vibration or movement at the display console.
