page 29
COMMERCIAL PRODUCTS DIVISION
KEYS ON THE DISPLAY CONSOLE
The Precor treadmills have an easy-to-use keypad that is activated by the slightest
touch. Remind users that they only need to apply gentle pressure to these ultra-
sensitive keys.
Each key on the display console’s keypad provides specific functions. Numeric keys
(numbered 1 - 0) let you enter data in answer to the display prompts and change
the speed or incline during a workout. The standard keys, CHANGE, RESET,
INCLINE ▲▼, SPEED CONTROL ▼▲, and ENTER, let you enter data as well as
control your workout.
The following information explains the different uses of the keys from left to right.
To locate each key, look at the display console or refer to Diagram 22.
Diagram 22
Display console keypad.
Numeric keys: Indicate program
#, time limit, or goal entries.
During a workout, use these
keys to select a target speed
or incline.
Note: The CHANGE keys are not shown in this diagram. Refer to Diagram 21 for
its location.
QUICKSTART
TM
: Bypasses the remaining
Setup prompts and starts moving the
running belt. SmartRate
®
is inactive and
default values apply.
KEYPAD TIPS
Select accurate entries or features such as SmartRate
®
will not work properly.
Answer the Setup prompts by pressing the numeric keys or the or keys.
Press ENTER to select the information being displayed.
QUICKSTART bypasses further selections and causes the running belt to
start moving. Default values apply (see QUICKSTART on page 31). The
SmartRate
®
display does not appear.
A time-out occurs during the Setup prompts if the treadmill detects no key
presses for 5 seconds. Prompts appear requesting that the user press the
arrow or number keys. If no key presses occur within the next 2 minutes, the
display returns to the Precor banner.
Press RESET to return to the Precor banner.
The STOP button does not appear in Diagram 22, but its function is vital as
explained in this section.

Table of Contents

Other manuals for Precor C954i

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Precor C954i and is the answer not in the manual?

Precor C954i Specifications

C956i

Power IconPower
motor power3.2 hp continuous duty
power requirement120/240 VAC 50/60Hz
Performance IconPerformance
speed range0.5 to 12 mph (1 to 20 kph)
incline range0 to 15% grade
Weight and Dimensions IconWeight and Dimensions
length86 inches (218 cm)
width37 inches (93 cm)
height55 inches (140 cm)
weight365 lbs (166 kg)
shipping weight460 lbs (209 kg)
running surface60 inches by 20 inches (153 cm by 51 cm)

C954i

Power IconPower
motor power3.2 hp continuous duty
power requirement120/240 VAC 50/60Hz
Performance IconPerformance
speed range0.5 to 12 mph (1 to 20 kph)
incline range0 to 15% grade
Weight and Dimensions IconWeight and Dimensions
length86 inches (218 cm)
width37 inches (93 cm)
height55 inches (140 cm)
weight365 lbs (166 kg)
shipping weight460 lbs (209 kg)
running surface60 inches by 20 inches (153 cm by 51 cm)
