EFX576i Elliptical Fitness Crosstrainer Assembly Guide 2

Hardware Kit (not to scale)

Fasteners Quantity

(A) Buttonhead screw (1-inch)

(B) Washer (⁵⁄₁₆-inch)

(D) Split washer (⁵⁄₁₆-inch)

(E) Hex head screw (1¼-inch)

(F) Washer (³⁄₈-inch)

(G) Self-tapping screw (1½-inch)

(H) Phillips-head screw (¾-inch)

2 — Bushings (J)

2 — Link arm caps (K)

2 — Pivot arm caps (L)
