Assembling the EFX 35
Leveling the EFX
Make sure the unit is level before allowing anyone to use it.
CAUTION: To eliminate movement, make sure the adjustable feet
are in contact with the floor.
To level the unit:
1. Gently rock the unit. If there is any movement, ask your
assistant to tip the unit to one side while you locate the
adjustable feet.
2. Correct the height of each adjustable foot as follows.
If you want to … Then turn the adjustable feet …
Raise the unit Counterclockwise
Lower the unit Clockwise
Figure 21: Rubber pad and adjustable foot locations
Important: Place the unit on a flat surface. Rotating the
adjustable feet cannot compensate for extremely uneven surfaces.
When you are finished adjusting the unit, place the unit on the
floor and recheck that it is level.
