page 5
12. If necessary, rotate the level adjustors (on the rear crossbar) so that your unit is level.
See Diagram 6.
13. Remove the power cord from the plastic bag.
Level the unit.
Diagram 6
Rear casing
Rear crossbar
Level adjustor
Connect the power cord.
Diagram 7
Rear casing
I/0 (ON/OFF) switch
Power plug receptacle
Power cord connection
14. Plug one end of the power cord into the receptacle at the rear of the unit. See Diagram 7.
Plug the other end into a standard 120v household outlet.
15. Your EFX is ready to use. Please continue on to
Understanding the Electronic Console
to
familiarize yourself with the electronic console display.
