34 Assembling and Maintaining TRM 800-Series Treadmills
Cable Connector Type Circuit
Connector
Location
TV in F-type coaxial
Power Two-contact plug,
polarized and latched
Data from base unit Eight-contact modular, on
flat gray cable
Heart rate sensors Four-contact strip, keyed
Safety key
(treadmills only)
Six-contact strip, keyed
CSAFE Eight-contact modular, on
flat gray cable
Auto Stop sensor
(treadmills only)
Four-contact strip, keyed
To simplify installation and maintenance, route and connect
cables 1 through 5 according to the following instructions.
Note: In the illustrations in this section, some cables are
omitted for the sake of clarity.
Connecting the Television Cable
The console’s television tuner is mounted inside the console’s
back plate. The tuner includes a short cable adapter that
allows the television cable to be connected outside the back
plate.
To connect the television cable:
1. Pull the cable out through the lower right corner of the
back plate.
2. Route the cable counterclockwise around the outside of
the back plate.
3. Attach the connector on the cable to the connector on the
tuner cable and tighten the two connectors securely using
two ⁷₁₆-inch open-end wrenches. Position both
connectors above the upper right corner of the back plate.
4. Use a plastic tie to secure the connectors to the top of the
back plate. Pass the tie through the two small holes near
the upper right corner of the back plate, then wrap it
around the connectors and tighten it securely. Cut off and
remove the protruding end of the tie.
