Console Configuration Precor P62 (w/media adapter)
HOW IT WORKS
The Precor console can be configured to tune antenna signals directly or it can be
configured to operate directly with either of these Set Top Boxes (no CAB required):
· DirecTV
· Enseo
CONSOLE CONFIGURATION
The information in this section is critical to successful deployment – please read
carefully! The information in this section is a brief summary, please reference the
following precor documents listed below for additional information and details:
https://precor-articulate.s3.amazonaws.com/ServiceManuals/SM-
HTML5Output/P82Console/Content/PDF/P82ConsoleServiceManual-20039-181.pdf
The Precor Media Adapter console sends IR control signals to these STBs via an IR
Emitter connected to a cable from the console.
The CAB allows the console to control a wider variety of STBs by intercepting the
console’s IR control signal, interpreting it, and then retransmitting in any of the IR
STB protocols supported by CAB. The custom cable connects the CAB to the console’s
USB (solely to provide power to the CAB) and also to the console’s IR emitter cable in
order to receive the STB control output signal.
The CAB knows how to receive and interpret the control signals for the Enseo STB
only. Therefore, the console must be configured as if it was being used with an Enseo
STB (see details in next section). The correct signal will go to the CAB and it will
translate into any of its other supported STB signal formats.
