©2019 Precor Inc. | Leg Extension RSL 605 | Assembly Guide
4
Part #
Name
Quantity Part #
Name
Quantity
Seat frame
1
Washers, domed, silver
2
Main frame
1
End cap
1
Upper cross brace
1
Hole plugs
4
Lower cross brace
1
Weight plates 10 lb (4.5 kg)
23
Back brace
1
Weight labels
1
Arm assembly
1
Hex head screws M10 x 25 mm
2
Handlebars
1
Socket head cap screws (SHCS) M8 x 15 mm
2
Roller pad cap ring
1
Socket head cap screws (SHCS) M10 x 25 mm
2
Roller pad cap
1
Socket head cap screws (SHCS) M10 x 40 mm
2
Bumpers
4
Socket head cap screws (SHCS) M10 x 65 mm
2
Weight stack tower frame
1
Socket head cap screws (SHCS) M12 x 35 mm
8
Top plate assembly
1
Socket head cap screws (SHCS) M12 x 130 mm
2
Add-on weight spacer, 5-inch
1
Socket head cap screws (SHCS) M12 x 125 mm
2
Add-on weight 5 lb (2.2 kg)
1
Button head cap screws (BHCS) M10 x 125 mm
2
Add-on weight handle
1
Flat head cap screw (FHCS) M12 x 35 mm
1
Kick plate
1
Button head cap screw (BHCS) M6 x 15 mm
1
Weight stack spacer, 3-inch
1
Hex head screws 5/16-inch x 1½-inch
6
Guide rods
2
Washers, 9 mm
8
Guide rod with cap
1
Washers, 11 mm
9
Shroud, crown
1
Washers, 13 mm
12
Shroud, rear upper
1
Nylon lock nuts, M12
2
Shroud, front upper placard
1
Nylon lock nuts, M10
2
Shroud, rear lower
1
Washer, silver, 13.5 mm ID x 35 mm OD
1
Shroud, front lower
1
Washer, rubber, black
1
Shroud, rear middle
1
Retaining ring, small
1
Shroud, front middle (left/right)
2
Retaining ring, large
1
Shroud, top tray
1
Seat pad
1
Shroud, lower pulley cover
1
Roller pad
1
Cable retainer pin
1
Back pad
1
1
10
11
12
13
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
3
30
31
32
33
34
35
36
37
39
4
40
42
43
44
45
46
47
48
49
6
7
8
9
2
5
14
38
41
50
51
52
53
54
55
56
57
58
Parts List
