3.
Reinstall any resistance shaft hardware that could have fallen off during the shaft
removal including: the spacer , adjustment bolt nut , spring , and/or adjust-
ment knob cushion . Make sure that the hardware is reinstalled in the proper order.
4.
Reinstall the the shaft acorn nut and shaft lock nut .
a.
First tread the shaft lock nut onto the resistance shaft followed by the shaft
acorn nut .
b.
Then fully tighten the shaft 17 mm acorn nut . Thread the shaft lock nut far
enough onto the resistance shaft so that there is enough room to fully tighten the
acorn nut.
c.
Fully tighten the acorn lock nut against the shaft acorn nut . Use one 17
mm wrench to hold the shaft acorn nut tight while using another 17 mm
47
