Parts Lists and Diagrams
Parts List
Part Description Qty
1 Cylinder Head Cover Bolt 2
2 Cover, Cylinder Head 1
3 Gasket, Cylinder Head Cover 2
4 Plug, Spark 2
5 Bolt, Cylinder Head 8
6 Cylinder Head 1
7 Right Cylinder Head 1
8 Pin 4
9 Gasket, Cylinder Head 4
10 Cross-Band Veneer 2
11 Stud 4
12 Stud 4
13 Cover, Cylinder Head 1
14 Plug, Engine Oil 1
15 Ring, Seal 1
16 Crankcase 1
17 Pin 2
18 Washer, Flat 3
19 Arm, Governor 1
20 Seal, Oil 1
21 Bolt, Drain Plug 2
22 Washer, Flat 2
23 Seal, Oil 1
24 Strainer, Breath Groove 1
25 Piece, Breath 1
26 Gasket, Breath Groove 1
27 Gasket, Breath Groove 1
28 Plate, Breath Groove Cover 1
29 Clamp 1
30 Bolt 2
31 Bolt 2
32 Spring Wire Clamp 2
33 Breather Hose 1
34 Gasket, Inlet 2
35 Tube, Intake 1
36 Nut 4
37 Pump Assembly, Gasoline 1
38 Bolt 3
39 Sleeve, Gasoline Pump Rubber 2
40 Fuel Pump Bracket 1
41 Strainer, Fuel 1
42 Clamp 6
43 Tube, Negative Pressure 1
44 Tube, Negative Pressure 1
45 Clamp 2
46 Tube, Fuel 1
47 Separator, Gas and Oil 1
48 Tube, Fuel 1
49 Mouth, Negative Pressure 1
50 Sensor, Engine Oil 1
51 Bolt 2
52 Bolt 7
53 Bolt 2
54 Cover, Crankcase 1
55 Pin 2
56 Gasket, Crankcase 1
57 Seal, Oil 1
58 Tube, Suction Oil 1
59 Washer 1
60 Bolt 2
61 Bolt 2
62 Pin 2
63 Pump Assembly, Oil 1
64 Cover, Oil Pump 1
65 Spring, Pressure Relief Valve 1
66 Ball, Steel 1
67 Strainer, Oil 1
68 Gear Assembly, Governor 1
Part Description Qty
69 Oil Dipstick 1
70 Gasket, Oil Pump 1
71 Crankshaft Assembly 1
72 Washer, Thrust 1
73 Rod, Connecting 1
74 Piston 2
75 Pin, Piston 2
76 Clip, Piston Pin 4
77 Ring, The First 2
78 Ring, The Second 2
79 Ring Set, Oil 2
80 Nut, Valve Lock 4
81 Nut, Valve Adjusting 4
82 Rocker, Valve 4
83 Bolt, Valve Adjusting 4
84 Lifter, Valve 4
85 Tappet, Valve 4
86 Seat, Valve Spring 4
87 Check Ring 4
88 Clamp, Valve Lock 8
89 Spring, Valve 4
90 Guide, Seal 4
91 Retainer, Valve Spring 2
92 Valve, Exhaust 2
93 Valve, Intake 2
94 Camshaft Assembly 1
95 Washer, Camshaft 1
96 Shield, Shroud 1
97 Screw 3
98 Shroud Nut 4
99 Shroud Assembly 1
100 Air Cleaner Front Cover 1
101 Air Cleaner Front Knob 2
102 Shroud 2, Cylinder Body 1
103 Diode 1
104 Shroud, Cylinder Body 1
105 Shield, Lower 1
106 Bolt 13
107 Sensor, Pressure 1
108 Shield, Crankcase Side 1
109 Bolt, Flange Shoulder 1
110 Lifting Bracket 2
111 Flange Shoulder Bolt 1
112 Shield 1
113 Shield 1
114 Gasket, Oil Filter Cover 1
115 Oil Filter Block 1
116 Ring, Seal 1
117 Tube, Oil Filter Installation 1
118 Oil Filter 1
119 Washer, Flat 2
120 Adapter, Cooling Pipe 2
121 Clamp 4
122 Pipe, Cooling 1
123 Pipe, Cooling 1
124 Radiator Assembly 1
125 Bolt 2
126 Gasket 1
127 Regulator, Voltage 1
128 Clamp 1
129 Gasket, Carburetor 2
130 Gasket, Carburetor Insulator 1
131 Joint, Intake Tube 1
132 Bolt 2
133 Bolt 1
134 Washer 1
135 Tube, Air Cleaner Connecting 1
136 Bolt 4
