Prem-I-Air EH1908 - Symbols and Product Diagram; Unit Symbols and Meanings; Product Component Identification

SYMBOLS FROM THE UNIT AND USER MANUAL
PRODUCT DIAGRAM
1. Control Panel
2. Air outlet with adjustable Louver
3. Air Inlet with Air Filter
4. Power Cord
5. Recessed Handle
6. Air Exhaust
7. Drain opening with Sealing Plug
Note: the appearance is only for reference, please see the real product for detailed information.
warning
This unit uses a flammable refrigerant.
If refrigerant leaks and comes in contact with fire or heating part, there is risk of fire.
Read the USER MANUAL carefully before operation.
Further information is available in the USER MANUAL, SERVICE MANUAL, and the like.
Service personnel are required to carefully read the USER MANUAL and SERVICE MANUAL
before operation.
1
2
3
4
5
6
7
