Premier E Series - Blower Speed Settings

PREMIER E SERIES DUAL CAPACITY INSTALLATION AND MAINTENANCE MANUAL
19
3-No RPM / RPM
This dip switch configures the control to monitor the RPM output of an ECM/ECM2 blower motor.
4-AT EH board / Premier EH board
This dip switch configures the control to operate with the Premier Electric Heat control board
(6 position connector) or with the Premier Electric Heat control board (3 position connector).
5-Future Use.
ECM2 fan motors have a 12-speed selector dip switch on the Premier E logic board (SW1)
and are factory set for optimum performance. To change speeds, select the appropriate speeds
on dip switch SW1. Consult the ECM2 fan performance table below for specific airflow and switch
information.
Blower Speed
ECM Fan
Performance
Data
MODEL
MAX AIR FLOW DIP SWITCH SETTINGS
ESP 123456789101112
E036 0.50 600 700 800 900 1000 1100 1200 1300 1400 1500 1550 1600
L MH
E048 0.50 600 700 800 900 1000 1100 1200 1300 1400 1500 1550 1600
L MH
E048 0.75 750 900 1000 1200 1400 1600 1700 1850 2000 2200 2300 2400
w/1 hp* L MH
E060 0.75 750 900 1000 1200 1400 1600 1700 1850 2000 2200 2300 2400
L MH
E072
0.75 750 900 1000 1200 1400 1600 1700 1850 2000 2200 2300 2400
L MH
Factory settings are at recommended L-M-H DIP switch locations CFM is controlled within ± 5% up to the maximum ESP
M-H settings must be located within boldface CFM range Max ESP includes allowance for wet coil and standard filter
* With optional one horsepower fan motor Lowest and highest dip switch setting are assumed to be L and
H speed, respectively
A 12 position DIP switch package on the Premier E control allows the airflow levels to be
set for Low, Medium, and High speed when using the ECM2 blower motor.
Only three of the DIP switches can be in the “ON” position. The first “ON” switch
(the lowest position number) determines the “Low Speed Fan” setting. The second “ON”
switch determines the “Medium Speed Fan” setting, and the third “ON” switch determines
the “High Speed Fan” setting.
The example to the right shows SW1 on the Premier E control board configured for the
following E036 airflow settings:
Low Speed Fan: 600 CFM
Medium Speed Fan: 800 CFM
High Speed Fan: 1200 CFM
1
2
3
4
5
6
7
8
9
10
11
12
SW1 On
