Premier E Series - General Installation Information

2
PREMIER E SERIES DUAL CAPACITY INSTALLATION AND MAINTENANCE MANUAL
Physical Data
UNIT LOCATION
Locate the unit in an indoor area that allows for easy removal of the filter and access panels.
Location should have enough space for service personnel to perform maintenance or repair. Provide
sufficient room to make water, electrical and duct connection(s). If the unit is located in a confined
space, such as a closet, provisions must be made for return air to freely enter the space by means of a
louvered door, etc. Any access panel screws that would be difficult to remove after the unit is installed
should be removed prior to setting the unit. On horizontal units, allow adequate room below the unit for
a condensate drain trap and do not locate the unit above supply piping. Care should be taken when
units are located in unconditioned spaces to prevent damage from frozen water lines and
excessive heat that could damage electrical components.
General
Installation
Information
MODEL E036 E048 E060 E072
Fan Wheel 11 X 10 11 X 10 11 X 10 11 X 10
Fan Motor ECM-1/2 ECM-1/2* ECM-1 ECM-1
Compressor
Air Coil:
Dimensions 28 x 25 32 x 25 36 x 25 36 x 25
Area (sq. ft.) 4.9 5.6 6.3 6.3
Rows 3 3 3 3
R410A (oz) 61.0 77.0 100.0 103.0
Weight (lbs) 320.0 336.0 399.0 426.0
Filter - 1"
Disposable
Electrostatic
Electronic
*Optional 1 hp ECM2 fan motor available
Bristol Twin Single
EAC3036
(1) 30 x 36
EAF3036
Horizontal Units
MODEL E036 E048 E060 E072
Fan Wheel 11 X 10 11 X 10 11 X 10 11 X 10
Fan Motor ECM-1/2 ECM-1/2* ECM-1 ECM-1
Compressor
Air Coil:
Dimensions 20 x 30 20 x 35 20 x 40 20 x 45
Area (sq. ft.) 4.9 4.9 5.6 6.3
Rows 3 3 3 3
R410A (oz) 58.0 81.0 97.0 103.0
Weight (lbs) 337.0 339.0 429.0 456.0
Filter-1" (1) 20 X 20
Disposable (1) 20 X 25 (2) 20 X25
Electrostatic EAF2042 EAF2048
Electronic EAC2042 EAC2048
*Optional 1 hp ECM2 fan motor available
Bristol Twin Single
(2) 20 X 20
EAF2037
EAC2037
Vertical Units
